14. MAGSEP-100 MAGNETIC SEPARATOR.

MAGSEP-100 Magnetic Separator for FH-100, HFH-100,
LPFR-3000, PFR-3000, HLPFR-3000 and HPFR-3000 flux
recovery separators. The MAGSEP-100 installs in place of the
standard slag tray. Its advanced design provides a slag
separation tray and powerful magnets to remove magnetic
particles from recovered flux. Magnetic particles are easily
disposed of by removing MAGSEP-100 from the flux recovery
machine, operator then slides magnet assembly out of mag-
netic collection tubes and magnetic particles fall away to be
discarded.

15. MAGSEP-100-E/P MAGNETIC SEPARATOR.

MAGSEP-100-E/P Magnetic Separator for FH-100-E/P, HFH-
100-E/P, SUPER-FH-100-A/P-E/P and SUPER-HFH-100-A/P-
E/P, installs in place of the standard slag tray. Its advanced
design provides a slag separation tray and powerful magnets to
remove magnetic particles from recovered flux. Magnetic
particles are easily disposed of by removing MAGSEP-100-E/P
from the flux recovery separator, operator then slides magnet
assembly out of magnetic collection tubes and magnetic
particles fall away to be discarded.

16. FT-100 - 100 POUND CAPACITY FLUX TROUGH

The FT-100 - 100 pound capacity flux trough is used under
small parts where flux spills off and needs to be recovered. It
is also used for loading flux into hopper/separators which are
not easily accessible. (See Technical Bulletin TB-MM708
figure nos. 7, 8, 13, 14 and 15.)
