IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

24. FV-1 IN-LINE FLUX VALVE.
The FV-1 in-line flux valve is for hand-held sub-arc guns and
PFR-LD3 lid. Trouble free valve fits inside diameter flux hose.
Installs in minutes and is ready to use.

FV-1-1/2" (For 1/2" I.D. Hose)

FV-1-3/4" (For 3/4" I.D. Hose)

FV-1-1" (For 1" I.D. Hose)

25. PRESSURE FEED HOSE.

A. 1/2".....................................................................................................................
B. 3/4".....................................................................................................................
C. 1" .......................................................................................................................
D. 3/4” High Temperature Hose (Max. 450ºF {232ºC})..............................................
E. 1” High Temperature Hose (Max. 450ºF {232ºC})..................................................

26. TWO INCH (2") VACUUM HOSE.

(Hose between Mighty-Mac vacuum unit and hopper/separator.)

A. 10 feet ................................................................................................................
B. 15 feet ................................................................................................................
C. 20 feet ................................................................................................................
D. 25 feet ................................................................................................................

Longer hose available in increments of five (5) feet.
27. 1-1/2" HEAVY DUTY HIGH ABRASION FLUX RECOVERY HOSE.

From hopper/separator to point of flux pick-up. This is our special “YELLOW” ultra-high abrasion hose
designed for very rugged recovery applications.

A. 5 feet .................................................................................................................
B. 10 feet ................................................................................................................
C. 15 feet ................................................................................................................
D. 20 feet ................................................................................................................
E. 25 feet ................................................................................................................
Longer hose available in increments of five (5) feet.

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
