Page 93 - Weld Engineering Product Selection Pages
P. 93
34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD” Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018
IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)
36. FD-1 FLUX DAM FOR BUILDING UP SMALL DIAMETER ROLLS.
The FD-1 Flux Dam “dams” flux on cylindrical welding
applications, to enable proper flux coverage and keeps flux
from cascading off the cylinder.
37. FLUX PICK-UP NOZZLES.
A. NZ-1; Standard Flux Pick-up Nozzle.
B. NZ-1-4; 4" Wide Flux Pick-up Nozzle.
(NEW PRODUCT!)
C. NZ-1CRN; Corner Weld Flux Pick-up Nozzle.
(Sold as a pair, one left nozzle, one right nozzle.)
D. NZ-1BUTT; Butt Weld Flux Pick-up Nozzle.
E. NZ-2; 2” Hose Dia. Flux Pick-up Nozzle.
* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
