IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

21. TNOZ-”x” PRESSURE TANK FLUX FEED NOZZLES.

1. TNOZ-1/2" - Pressure tank flux feed nozzle for 1/2" I.D. hose.
Nozzle fits 2" NPT female pipe fitting which is standard on PFR-3,
“x”PFR-3000, “x”PT-”x”00 and Lincoln K320 tanks. (Please
consult factory for non-standard sizes.)
2. TNOZ-3/4" - Same as above,except for 3/4" I.D.
flux feed hose.

3. TNOZ-1" - Same as above, except for 1" I.D.
flux feed hose.

4. TNOZ-DUAL-1/2" - Same as above, except for 1/2" I.D.
flux feed hose.

5. TNOZ-DUAL - 3/4" - Same as above, except for 3/4" I.D.
flux feed hose.

6. TNOZ-DUAL-1" - Same as above, except for 1" I.D.
flux feed hose.

22. TANK HIGH/LOW SENSOR.
High or low flux level warning lights or audible alarm for flux level.
See page 38 - 39 for sensor options.

23. FFC-1 FLUX FILLING CONE.

The flux filling cone is for easily adding flux to the PT-”x”00 and HPT-”x”00
flux pressure feed tank systems.

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
