38. PIPE MILL ID OR OD PICK UP NOZZLES - PIPE SIZES FROM 24” TO 42” OD. (Two inch recovery hose
required).

A. NZ-2-STR-24-45-ID Straight, ID pick up nozzles (24” to 42” PIPE DIA.)

B. NZ-2-ANGLE 24-45-ID angle pick up nozzles (24” to 42” PIPE DIA.)

C. NZ-2-STR-24-45-OD Straight OD pick up nozzles (24” to 42” PIPE DIA.)

D. NZ-2-ANGLE 24-45-OD angle pick up nozzles (24” to 42” PIPE DIA.)

(Larger sizes are available, please contact factory for information and pricing.)

39. SPECIAL DESIGN NOZZLES AVAILABLE FOR SPECIFIC NEEDS. CONSULT FACTORY FOR DETAILS.

40. POWER WAND

The Power Wand, adjustable loading nozzle, increases air flow to carry newly opened flux from the bag or
container into the hopper fast and effectively.

A) PW-1500 for 1-1/2” Recovery Hose.
B) PW-2000 for 2” Recovery Hose

PW-1500 OR PW-2000

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
