IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

28. 1-1/2" STANDARD DUTY FLUX DISPENSING/RECOVERY HOSE.

From hopper/separator to welding equipment hopper or welding torch.

A. 5 feet...................................................................................................................
B. 10 feet...................................................................................................................

Longer hose available in increments of five (5) feet at $8.60/ft.

29. MOUNTING BRACKETS.

A. The FHM-1 provides easy positioning of hose over flux.
(Linear adjustment only.) For use with all Mighty-Might
and Mighty-Mac Recovery Systems.

B. The FHM-1ADJ provides easy positioning of hose over
flux. (Linear and angular adjustment.) For use with all
Mighty-Might and Mighty-Mac Recovery Systems.

30. FCV-3000.

The FCV-3000 flux control valve with 8" nozzle is used on
end of flux dispensing hose (1-1/2") to control flux flow
rate to welding equipment hopper or torch.

31. F/A-3000.

The F/A-3000 flux recovery line shut-off valve for 1-1/2"
hose (i.e., Shut off one recovery line; open another.)

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
