IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

17. FF-3 FLUX FEED PIPE.

The FF-3 flux feed pipe enables flux to be fed from a pressure feed tank (PT-”x”00 or other pressure tank is
required) to the flux hopper. Flux flow to hopper will automatically stop when flux level inside hopper is higher
than inlet pipe. Specify flux feed hose size (1/2", 3/4" or 1" I.D. size available.)

FF-3-1/2" for 1/2" I.D. hose
FF-3-3/4" for 3/4" I.D. hose
FF-3- 1" for 1" I.D. hose

18. PFR-LD3 LID.

The PFR-LD3 Lid is for attachment to most manufacturer’s standard flux
hoppers (please specify model of hopper used when ordering), to pressure
feed flux to the hopper from a flux feed pressure tank (“x”PT-”x”00, LPFR-
3000 and PFR-3000 systems). Customer has choice of 1/2", 3/4" or 1" I.D.
hose fitting.

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
