IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

9. HEATED HPFR-3000 FLUX RECOVERY SYSTEM.

The HPFR-3000 flux recovery system is the same as item 8, except that
the upper flux hopper is heated (tank is not heated). Continuous control
to 250°F (121°C). (Input of 60 psi of compressed air @ approximately 2
cfm is required.) Please specify voltage, 115v/1ph/50-60hz or 220v/1ph/
50-60hz. (See pg. 79, item 14 {MAGSEP-100} for optional magnetic
separator and TB-MM708 figure nos. 21, 22 and 23 for complete system
requirements.)

A. HPFR-3000-H200/100 - 150 Lb. Capacity Heated Hopper/Separator
100 Lb. Capacity Pressure Feed Tank

B. HPFR-3000-H300/300 - 300 Lb. Capacity Heated
Hopper/Separator 300 Lb. Capacity Pressure Feed Tank

C. HPFR-3000-H400/600 - 400 Lb. Capacity Heated
Hopper/Separator 600 Lb. Capacity Pressure Feed Tank

D. HPFR-3000-H1000/1200 -1000 Lb. Capacity Heated
Hopper/Separator 1200 Lb. Capacity Pressure Feed Tank

E. HPFR-3000-H1500/2000 - 1500 Lb. Capacity Heated
Hopper/Separator 2000 Lb. Capacity Pressure Feed Tank
(Note: Available in 220v/3ph/50-60hz or 380-415v/3ph/50-60hz only.)

ELECTRONIC FLUX LEVEL SENSOR:
Optional high temperature electronic high or low flux level sensor is available to sense flux level of pressure
tank or flux hopper. When flux level is low (or high; based on your requirements), a loud audible
alarm and flashing light on control panel will signal operator. (See page 38 - 39 for sensor options and pricing.)

OPTIONAL FTV-3000 and AV-3000-NS AUTOMATIC FLUX TRANSFER VALVE.........NEW PRODUCT!
Please see page 71 and 72 for details.115V/1PH/60-50HZ (Other voltages available upon request. Call for
pricing details.)

**Please note, the HPFR-3000 flux pressure feed and recovery system is manufactured with an internal flux
cone. This cone allows complete draining of all flux out of the tank. There is no stagnant area in the tank
from which flux will not flow out of the tank.

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
