Page 37 - Weld Engineering Product Selection Pages

34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD”
Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018

ACCESSORIES FOR THE FOLLOWING FLUX RECOVERY AND FLUX HANDLING SYSTEMS:

AP-1 AS-4 ALT-2
SUPER-AP-1 AS-4-E/P ALT-2-C
AP-1-E/P PS-2 PFR-3
SUPER-AP-1-E/P PS-2-A/P PFR-3-A/P
XP-3 SUPER-PS-2-A/P SUPER-PFR-3-A/P
XP-4T APT-2 LPFR-3
SUPER-FH-100-A/P APT-2-C LPFR-3-A/P
SUPER-HFH-100-A/P XP-3TRAC SUPER-LPFR-3-A/P
SUPER-FH-100-A/P-E/P XP-3TRAC-C PT & HPT-”x”00
SUPER-HFH-100-A/P-E/P

1. AV-4 ELECTRIC AIR VALVE. (For all air powered Flux Vacs.)

The AV-4 electric air valve is for remotely turning air
powered flux recovery vacuums on and off (AP-1,
SUPER-AP-1, AP-1-E/P, SUPER-AP-1-E/P, XP-3, XP-4T,
XP-3TRAC, APT-2, PS-2-A/P, SUPER-PS-2-A/P, and FH-
100-AP etc.). The AV-4 is installed between the on/off
ball valve of the flux vac, and the air supply. When
electrical signal is provided to the AV-4, the valve opens,
allowing the flux vac to operate. Standard input voltage is
115V. (Also available in other voltages.)
See pages 2, 3, 5, 6, 8, 9 and 12 for typical installa-
tions.

2. FLUX HOSE MOUNTING BRACKETS.

A. The FHM-1 provides easy positioning of hose
over flux. (Linear adjustment only.) For use
with all Mighty-Might and Mighty-Mac Recov-
ery Systems.

B. The FHM-1ADJ provides easy positioning of
hose over flux. (Linear and angular adjust-
ment.) For use with all Mighty-Might and
Mighty-Mac Recovery Systems.
