Page 36 - Weld Engineering Product Selection Pages
P. 36
34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD”
Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018
2. STATIONARY SUBMERGED ARC FLUX OVENS (CONTINUED)
THE FO-700 FLUX OVEN HAS BEEN REPLACED BY THE FO-700 HT
HIGH TEMPERATURE FLUX OVEN. IMPORTANT NOTE: THE FO-700 HT
FLUX OVEN WILL BE PRICED AT THE SAME PRICE AS THE FO-700.
THIS WILL SAVE OUR CUSTOMERS SEVERAL THOUSAND DOLLARS
PLUS THE BENEFIT OF THE HIGH TEMPERATURE RANGE OF THE FO-
700 HT!
A. The FO-700 HT Flux Oven has a 700 pound storage capacity. Total and
uniform heating of flux is accomplished with 4500 watts of power. Eighteen
(18) powerful Incoloy sheathed heating elements are submerged in
the flux (not on the side walls as in many competitive models).
Temperature range is from 32 °F to 700 °F (0 °C to 371 °C) with digit al
display for easy reading. The Oven is rugged for industrial in-plant use.
Internal oven compartment vents any pressure buildup. The unit comes
complete and ready for use.
Input power: 220v/1ph/60-50hz
Input power: 460v/3ph/60hz
(Other voltages are available. Please advise voltage required for exact
pricing.)
B. The FO-700 HT-AB is the same as the FO-700 HT above, except it is a programmable flux re-bake oven. This oven
re-bakes flux at an adjustable temperature range setting of 32 °F to 700 °F (0 °C to 371 °C), for a selected amount
of time -- 3 minutes to 999 hours (factory pre-set at 3 hrs.). After the bake time has elapsed the oven will shift to a
storage mode with a temperature range of 32 °F to 700 °F (0 °C to 371 °C). The storage temperature is maintained
until the Re-bake button is pushed again. Large push buttons make operation very easy. The unit comes com-
plete and ready for use.
Input power: 220v/1ph/60-50hz
Input power: 460v/3ph/60hz
(Other voltages are available. Please advise voltage required for exact pricing.)
page 29 2018 PRODUCT SELECTION WITH PRICES.PMD
