IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

4. FH-100 FLUX HOPPER/SEPARATION CHAMBER.

The FH-100 Flux Hopper/Separation Chamber has approxi-
mately a 150 lb. capacity with a slag tray, two large sight
window level indicators, and a filter which prevents slag from
being drawn into the vacuum unit. (See pg. 61, item C
{MAGSEP-100} for optional magnetic separator.) (See Technical
Bulletin TB-MM708 figure nos. 2, 9, 10, 11, 12, 13, 14, 15, 17,
and 18.)

A. FH-300 Flux Hopper/Separation Chamber is same as above except the
FH-300 has a 300 lb. capacity.

B. FH-600 Flux Hopper/Separation Chamber is same as above except the
FH-600 has a 600 lb. capacity.

C. FH-1000 Flux Hopper/Separation Chamber is same as above except the
FH-1000 has a 1000 lb. capacity.

5. HFH-100 HEATED FLUX HOPPER/SEPARATION CHAMBER.

The HFH-100 Heated Flux Hopper/Separation Chamber is same
as item no.4, except heated. Continuous control to 250°F
(121°C.) Please specify volt age, 115v/1ph/50-60hz or 220v/1ph/
50-60hz. (See pg. 61, item C {MAGSEP-100} for optional
magnetic separator.) (See Technical Bulletin TB-MM708 figure
nos. 2, 9, 10, 11, 12, 13, 14, 15, 17, and 18.)

A. HFH-300 Heated Flux Hopper/Separation Chamber is the same as above
except the HFH-300 has a 300 lb. capacity.

B. HFH-600 Heated Flux Hopper/Separation Chamber is same as above
except the HFH-600 has a 600 lb. capacity.

C. HFH-1000 Heated Flux Hopper/Separation Chamber is same as above
except the HFH-1000 has a 1000 lb. capacity.

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
