Page 63 - Weld Engineering Product Selection Pages
P. 63
34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD” Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018
IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)
NEW PRODUCT!
MV-5 LOW COST, HEAVY DUTY RECOVERY SYSTEM
The NEW MV-5 (Complete with the FHMV5-100 HOPPER) is a low cost, heavy duty flux recovery system which
is ideal for Girth Welding (3 O’clock storage tank welding).
Input power: 115v/1ph/60hz / 7.5amp input, 3/4 HP vacuum motor.
*SMALL HEAVY DUTY ELECTRIC FLUX VACUUM.
*COMES WITH FHMV5-100 FLUX HOPPER (100 LB CAPACITY).
*PERFECT FOR GIRTH WELDERS.
*VERY QUIET. NO HIGH PITCH SOUND.
*115 VAC PLUGS INTO MOST WELDERS.
*DUST FALLS INTO REMOVABLE DUST PAN.
*VERY LOW MAINTENANCE.
FHMV5-100 100LB CAPACITY
*REQUIRES NO COMPRESSED AIR.
HOPPER. COMES WITH MV-5
SYSTEM
* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
page 56 2018 PRODUCT SELECTION WITH PRICES .PMD
