Page 60 - Weld Engineering Product Selection Pages

34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD” Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018

NEW PRODUCT!

7.5 HP PORTABLE HEATED FLUX RECOVERY SYSTEM

THE HPS-7500 HAS SEMI-AUTOMATIC FILTER CLEANING (PUSH A BUTTON TO CLEAN THE FILTER.
DUST FALLS INTO A DRAWER FOR EASY REMOVAL.), 200 LB HEATED FLUX HOPPER/SEPARATOR
(THE HOPPER IS HEATED TO AN ADJUSTABLE 32°F/0°C to 250°F/121°C) AND CONTINUOUS DUTY
VACUUM BLOWER/MOTOR UNIT ARE ALL MOUNTED ON A PORTABLE UNDERCARRIAGE.

4. HPS-7500 (PORTABLE HEATED 7.5 HP FLUX RECOVERY SYSTEM)
Input power: 220-460v/3ph/60hz
Input power: 380-415v/3ph/50hz
Input power: 575v/3ph/60hz

OPTIONAL
OPTIONAL 2” MAGSEP-100
RECOVERY HOSE MAGNETIC
SEPARATOR FLUX LEVEL
INDICATOR
WINDOWS
DUST AND FINES
COLLECTION OPTIONAL
UNIT WITH PUSH NZ-1 FLUX
BUTTON CLEANING PICK-UP NOZZLE
CONTINUOUS DUTY
VACUUM BLOWER MOTOR. NO V-
BELTS OR OIL BATH FILTERS TO
DUST SERVICE.
DRAWER
FLUX DISPENSING
VALVE
PS-7500 HPS-7500
FRONT VIEW SIDE VIEW

ADDITIONAL ACCESSORIES HPS-7500:

2-1/2” Vacuum Hose (sold in 5 ft increments).
2” Flux Recovery Hose (sold in 5 ft increments).
NZ-2” Flux Pick-Up Nozzle.2-1/2” Vacuum
Teflon Filter for Extra Heavy Duty Recovery

MAGSEP-100 Magnetic Separator for HPS-1500, HPS-3000, HPS-5000 and HPS-7500
flux recovery units available.
See page 61, Item C.
