LOW COST HEAVY CONTINUOUS DUTY STATIONARY FLUX
RECOVERY EQUIPMENT

THE SPS-1500, SPS-3000, SPS-5000, AND SPS-7500 HAVE SEMI-AUTOMATIC FILTER CLEANING (PUSH A
BUTTON TO CLEAN THE FILTER. DUST FALLS INTO A DRAWER FOR EASY REMOVAL.), YOUR CHOICE OF
EITHER THE FH-100 (150 LBS CAPACITY) FLUX HOPPER/SEPARATOR OR THE MS-1 SEPARATOR. THE
CONTINUOUS DUTY VACUUM BLOWER/MOTOR UNIT AND SEMI-AUTOMATIC DUST COLLECTION UNIT
ARE MOUNTED ON A STURDY UNDERCARRIAGE.

FH-100 (150 LBS CAP.) (OPTIONAL
HEATED HFH-100 HOPPER,
ELECTRONIC HI/LOW SENSOR
OPTIONAL 2” WITH ALARM, LARGER HOPPERS OPTIONAL 2” OPTIONAL 1-1/2”
VACUUM HOSE AND DOUBLE INLET AND/OR VACUUM HOSE RECOVERY HOSE
OUTLET ARE AVAILBLE). OPTIONAL
OPTIONAL MAGNETIC
MAGNETIC SEPARATOR
SEPARATOR OPTIONAL 1-1/2” AVAILABLE
AVAILABLE RECOVERY HOSE
OPTIONAL 1-1/2” OPTIONAL
DISPENSING 52” MIN FOR SPS-1500(50HZ) FP-1 FLUX PORT
65” MIN FOR SPS-1500(60HZ)
HOSE 64” MIN FOR SPS-3000(50HZ)
80” MIN FOR SPS-3000(60HZ)
OPTIONAL 73” MIN FOR SPS-5000(50HZ) OPTIONAL
93” MIN FOR SPS-5000(60HZ)
FCV-3000 FHM-1 or
FLUX VALVE FHM-1ADJ
OPTIONAL FHM-1 or
CUSTOMER FHM-1ADJ OPTIONAL
PROVIDES NZ-1 FLUX
MOUNTING OPTIONAL NZ-1 FLUX PICK-UP
BRACKETS PICK-UP NOZZLE
NOZZLE
SYSTEM COMES WITH EITHER FH-100 SEPARATOR.... ....OR THE MS-1 SEPARATOR FOR THE SAME BASE PRICE.

DUST AND FINES
COLLECTION
UNIT WITH PUSH
BUTTON CLEANING
CONTINUOUS DUTY
VACUUM BLOWER/
MOTOR. NO V-BELTS OR OIL
BATH FILTERS TO SERVICE.
DUST
DRAWER

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
