Page 27 - Weld Engineering Product Selection Pages
P. 27
34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD”
Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018
1. ALT-2-C MIGHTY-MIGHT ELECTRIC FLUX RECOVERY SYSTEM FOR LINCOLN CRUISER TRACTOR
MOUNTING.
The ALT-2-C electric flux recovery system is a lightweight
modular unit for Lincoln Electric’s Cruiser submerged arc
welding tractors. It recovers flux while welding and automati-
cally separates out dust, fines and slag. Places reusable flux
back into tractor flux hopper with dump valve. Equipped with
indicator light which flashes when dust bag needs to be
cleaned and “Flux Port” which enables new flux to be added
without interrupting the weld. Comes complete with five (5)
feet of recovery hose, four (4) feet of vacuum hose, mounting
brackets, standard FHM-1 flux hose mounting bracket, and
standard NZ-1 flux pick up nozzle. See pages 30 and 31 for
other accessories.
(Consult factory for mounting brackets for tractors other
than Lincoln.)
Input power: 115v/1ph/50-60 hz/9 amps
Input power: 220v/1ph 50-60 hz/4.5 amps
2. ALT-2 MIGHTY-MIGHT ELECTRIC FLUX RECOVERY SYSTEM FOR TRACTOR MOUNTING.
The ALT-2 electric flux recovery system is a lightweight
modular unit for Lincoln LT-7, Miller, and other automatic
submerged arc welding tractors. It recovers flux while welding
and automatically separates out dust, fines and slag. Places
reusable flux back into tractor flux hopper with dump valve.
Equipped with indicator light which flashes when dust bag
needs to be cleaned and “Flux Port” which enables new flux to
be added without interrupting the weld. Comes complete with
five (5) feet of recovery hose, four (4) feet of vacuum hose,
mounting brackets for LT-7, standard FHM-1 flux hose mount-
ing bracket, and standard NZ-1 flux pick up nozzle. See pages
30 and 31 for other accessories.
(Consult factory for mounting brackets for tractors other
than Lincoln.)
Input power: 115v/1ph/50-60 hz/9 amps
Input power: 220v/1ph 50-60 hz/4.5 amps
page 20 2018 PRODUCT SELECTION WITH PRICES.PMD
