Page 25 - Weld Engineering Product Selection Pages
P. 25
34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD”
Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018
“AIR POWERED” TRACTOR FLUX RECOVERY UNITS
1. APT-2-C “AIR POWERED” MIGHTY-MIGHT FLUX RECOVERY SYSTEM FOR LINCOLN CRUISER
TRACTOR MOUNTING.
The APT-2-C is a lightweight modular air
powered unit for Lincoln Electric’s Cruiser
submerged arc welding tractors. Powerful air operated
vacuum introduces no oil or water to the flux and pro-
duces no damage to recovered flux particles since
recovered flux is not in compressed air stream. Recov-
ers flux while welding and automatically separates out
dust, fines and slag. Places reusable flux back into
tractor flux hopper with dump valve. Comes complete with
six (6) feet of hose, mounting bracket, standard FHM-1
flux hose mounting bracket and standard NZ-1 flux pick
up nozzle. See pages 30 and 31 for other accessories.
(Consult factory for mounting brackets for tractors
other than Lincoln.)
Input power: Shop air (70-100 psi, 8 cfm
using minimum 1/4" I.D. air hose).
2. APT-2 “AIR POWERED” MIGHTY-MIGHT FLUX RECOVERY SYSTEM FOR
TRACTOR MOUNTING.
The APT-2 is a lightweight modular air powered unit for
Lincoln, Miller, and other automatic submerged arc
welding tractors. Powerful air operated vacuum intro-
duces no oil or water to the flux and produces no damage
to recovered flux particles since recovered flux is not in
compressed air stream. Recovers flux while welding and
automatically separates out dust, fines and slag. Places
reusable flux back into tractor flux hopper with dump
valve. Comes complete with six (6) feet of hose, mounting
bracket, standard FHM-1 flux hose mounting bracket and
standard NZ-1 flux pick up nozzle. See pages 30 and 31
for other accessories.
(Consult factory for mounting brackets for tractors
other than Lincoln.)
Input power: Shop air (70-100 psi, 8 cfm using
minimum 1/4" I.D. air hose).
