ELECTRIC POWERED FOR AUTOMATIC WELDING HEADS

1. AS-4 MIGHTY-MIGHT ELECTRIC FLUX VAC.

The AS-4 features flashing indicator light when dust bag
requires cleaning, flux level sight window in AS-4 and
lower hopper. The AS-4 mounts directly to standard
Lincoln flux hopper. Use MADP-1* adapter plate (*See
page 41 for mounting to Miller hopper). The AS-4 can be
adapted to any automatic welding head using optional FH-
1 or HFH-1 heated flux hopper (see page 34 and 35).
Comes complete with five (5) feet of hose, hopper
mounting brackets, NZ-1 nozzle and flux hopper sight
glass. (FHM-1 or FHM-1ADJ Flux Hose Mounting
Brackets and MAGSEP-1 Magnetic Separator are
optional, see pages 30 and 33).
See page 14 for recommended system order list.

Input power: 115v/1ph/50-60hz/9 amps

Input power: 220v/1ph/50-60hz/4.5 amps

2. AS-4-E/P AUTOMATIC FLUX TRANSFER MIGHTY-MIGHT ELECTRIC FLUX VAC.

Same as AS-4, except flux is automatically transferred to
lower hopper without operator input. In addition to the
above electrical input, it requires shop air (70-100 psi
with minimum 3/16" I.D. air hose. Air operates flux valve
only and does not provide vacuum). See page 15 for
recommended system order list.

Input power: 115v/1ph/50-60hz/9 amps

Input power: 220v/1ph/50-60hz/4.5 amps

IMPORTANT NOTE
24v control circuit for on/off pendant is available for AS-4, PS-2, LPFR-3 and PFR-3.
