Page 18 - Weld Engineering Product Selection Pages
P. 18
34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD”
Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018
9. SUPER-FH-100-A/P-E/P 150 POUND CAPACITY “AIR POWERED”
FLUX VAC WITH HOPPER/SEPARATOR.
Powerful air operated vacuum introduces no oil or water
to the flux and produces no damage to recovered flux
particles since recovered flux is not in compressed air
stream. The SUPER-FH-100-A/P-E/P is a 150 pound
capacity, automatic flux transfer, continuous feed recov-
ery unit with a slag tray, and two large sight window level
indicators. Comes complete with 5 feet of 1 1/2"
dispensing hose and 8 feet of 1 1/2" recovery hose, and
NZ-1 flux pick-up nozzle.
(Important note: This unit does not require a specific
“head height” above welding torch or hopper as
does the SUPER-FH-100-A/P.) See page 12 for
recommended system order list.
Input power: Shop air (14 cfm @ 70-100 psi,
using minimum 1/4" I.D. air hose).
115V/1PH/50-60HZ (Other voltages available).
10. SUPER-HFH-100-A/P-E/P 150 POUND CAPACITY “AIR POWERED”
FLUX VAC WITH HOPPER/SEPARATOR.
The SUPER-HFH-100-A/P-E/P is the same as the
SUPER-FH-100-A/P-E/P except heated. Continuous
digital thermostat control (ambient to 250°F {121°C}) and
large digital display for easy reading Please specify
voltage (115V/1PH/50-60HZ or 220V/1PH/50-60HZ).
See page 12 for recommended system order list.
Input power: Shop air (14 cfm @ 70-100 psi,
using minimum 1/4" I.D. air hose).
115V/1PH/50-60HZ (Other voltages available).
