Page 17 - Weld Engineering Product Selection Pages
P. 17

34 Fruit St.
                                           “MANUFACTURERS OF THE MOST COMPLETE LINE     Shrewsbury, MA 01545  (U.S.A.)
                                           OF FLUX HANDLING EQUIPMENT IN THE WORLD”
                                                                                        Telephone: (508) 842-2224
                                                                                        Fax: (508) 842-3893
                                                                                        Website:
                                                                                        www.weldengineering.com
                                                                                        Email:
                                                                                        [email protected]
                                                                                        March 1, 2018




            7.    SUPER-FH-100-A/P 150 POUND CAPACITY “AIR POWERED” FLUX VAC
                  WITH HOPPER/SEPARATOR.



                                                Powerful air operated vacuum introduces no oil or water
                                                to the flux and produces no damage to the recovered flux
                                                particles since recovered flux is not in the compressed air
                                                stream.  The SUPER-FH-100-A/P is a 150 pound capacity
                                                gravity feed recovery unit with a slag tray, and two large
                                                sight window level indicators.  Comes complete with 7 feet
                                                of 1 1/2" dispensing hose and 10 feet of 1 1/2" recovery
                                                hose, and NZ-1 flux pick-up nozzle.
                                                (See page 12 for recommended system order list.)

                                                Input power:  Shop air (14 cfm @ 70-100 psi,
                                                using minimum 1/4" I.D. air hose).















            8.      SUPER-HFH-100-A/P HEATED 150 POUND CAPACITY “AIR POWERED”
                  FLUX VAC WITH HOPPER/SEPARATOR.



                                                The SUPER-HFH-100-A/P is the same as the SUPER-
                                                FH-100-A/P, except heated. It has a Continuous digital
                                                thermostat control (ambient to 250°F {121°C}) and large
                                                digital display for easy reading..  Please specify voltage
                                                (115V/1PH/50-60HZ or 220V/1PH/50-60HZ).
                                                (See page 12 for recommended system order list.)

                                                Input power:  Shop air (14 cfm @ 70-100 psi,
                                                using minimum 1/4" I.D. air hose).
















                                                         page 10                2018 PRODUCT SELECTION WITH PRICES.PMD
   12   13   14   15   16   17   18   19   20   21   22
