17. FP-1 FLUX PORT.
The FP-1 flux port is for the Lincoln hopper or any flat walled
hopper. Allows additional flux to be added to hopper without
interrupting the weld. Includes aluminum port and pop-rivets.

18. AFV-2 AUTOMATIC FLUX VALVE.

The AFV-2 is an in-line flux pinch valve for 3/4" I.D. flux feed hose.
Automatically opens or closes flux flow in 3/4" I.D. hose, when 115v
electrical signal is supplied. Use with FH-1, HFH-1, or any gravity
feed hopper. (Typical use would be to automatically start flux flow
when arc-start button is pushed and stop flux flow when weld is
finished.) System includes flux pinch valve, air on/off solenoid,
pressure regulator and five (5) feet of 1/4" I.D. air hose.

Input power: 115v/1ph/50-60hz and standard shop air (available in
other voltages).

19. AFV-2-FH-100 AUTOMATIC FLUX VALVE.

Same as Item 18, except used with FH-100 or HFH-100. One end
accepts 1 1/2" I.D. flux dispensing hose from FH-100; other end
accepts 3/4" I.D. hose to feed welding torch.

Input power: 115v/1ph/50-60hz and standard shop air (available in
other voltages).

20. AFV-32 AUTOMATIC FLUX VALVE.

The AFV-32 is an automated slide valve attachment for 1" I.D. flux
feed hose. Automatically opens or closes flux flow in 1" I.D. hose,
when 115v electrical signal is supplied (other voltages available). Use
with FH-1, HFH-1, FH-100-E/P, HFH-100-E/P, SUPER-FH-100-A/P-E/
P and SUPER-HFH-100-A/P-E/P, or any gravity feed hopper. (Typical
use would be to automatically start flux flow when arc-start button is
pushed and to stop flow when weld is finished.) System includes
automated slide valve, air on/off solenoid, pressure regulator and two
five (5) foot lengths of 1/4" I.D. air hose.
* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
