Page 72 - Weld Engineering Product Selection Pages

34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD” Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018

IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

14. HFH-1 HEATED FLUX HOPPERS.

The HFH-1 heated flux hopper is the same as the FH-1 Hopper
(see page 64), except it is heated. It has a continuous digital
temperature control (34°F {1 °C } to 250°F{121°C}) with digital
readout for those applications where flux must be heated.
(Interfaces with same recovery equipment as FH-1 Hopper).
Please specify voltage, 115v/1ph/50-60hz or 220v/1ph/50-60hz.

A. HFH-1-60 heated flux hopper is the same as above except it
holds 60 lbs of flux.

15. HFH-3-PF HEATED FLUX HOPPER.
Compact, heated flux hopper for feeding to smaller I.D. welds.
Mounts directly to Lincoln and Miller welding equipment, in
place of standard hopper. Will also mount to other
manufacturer’s equipment. Holds approximately 7 lbs of flux.
Heats flux up to 250°F (121°C) with easy to use thermostat
control. Pressure feed system constantly feeds new flux to
hopper. Comes complete with auto-pneumatic flux valve with
external control. Please specify voltage, 115v/1ph/50-60hz or
220v/1ph/50-60hz.

16. HFH-4-PF heated flux hopper is the same as above except it holds 17 lbs of flux.

Compact, heated flux hopper for feeding to smaller I.D. welds.
Mounts directly to Lincoln and Miller welding equipment, in
place of standard hopper. Will also mount to other
manufacturer’s equipment. Holds approximately 17 lbs of flux.
Heats flux up to 250°F (121°C) with easy to use thermostat
control. Pressure feed system constantly feeds new flux to
hopper. Comes complete with auto-pneumatic flux valve with
external control. Please specify voltage, 115v/1ph/50-60hz or
220v/1ph/50-60hz.

*FOR FH-3 AND HFH-3 HOPPERS SEE PAGE 35

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
