Page 52 - Weld Engineering Product Selection Pages

34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD” Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018

IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

2A. MM-3000X (“MIGHTY-MAC 3000X”)

The new MM-3000X (“Mighty-Mac 3000X) heavy duty vacuum
and dust collector offers great new features. EXtremely rugged
and durable. EXtremely easy to maintain because large door to
filters open with the flick of latches, and all internal covers are
simply removed. EXtremely safe; micron filters remove particles
below one (1) micron. The air you breath will be much cleaner.
The MM-3000X also provides auto sensing dust cleaning logic
so filters are always automatically pulse cleaned as they
become dirty (with no operator intervention)! Motor: 4 hp,
TEFC directly coupled to blower.

Input power: 230v/60hz/3ph
nput power: 460v/60hz/3ph
Input power: 220v/50hz/3ph
Input power: 380-415V/50hz/3ph
Input power: 575v/60hz/3ph

2B. MM-3000X/P (“MIGHTY-MAC 3000X/P”)

MM-3000X/P (“Mighty-Mac 3000X/P”) Heavy-duty vacuum unit
only. Same as 2A above, except that instead of a dust drawer,
dust filter chamber has a hopper bottom. This enables continu-
ous dumping of dust to a much larger dust container below
Mighty-Mac (i.e. FD-55 dust drum ). Ideal for very continuous
recovery applications where regular emptying of dust drawer is
inconvenient. (See Bulletin TB-MM708 for descriptive diagrams).

TO ABOVE 2A PRICES ADD

Note: TEFLON COATED POLYESTER FILTERS. (Available
for use with the MM-3000X, MM-3000X/P, MM-5000X, MM-
5000X/P, and are standard in the MM-5000X-MILL.) Specify
these filters for extra heavy duty or dusty flux applications.
Filters last much longer and resist dust clogging. Two required.

ATTACH OPTIONAL FACTORY INSTALLED, ADD TO 2A MIGHTY-MAC VACUUM UNIT COST
FD-55 DUST DRUM
KIT HERE.

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*

page 45 2018 PRODUCT SELECTION WITH PRICES .PMD
