Page 51 - Weld Engineering Product Selection Pages

34 Fruit St.
“MANUFACTURERS OF THE MOST COMPLETE LINE Shrewsbury, MA 01545 (U.S.A.)
OF FLUX HANDLING EQUIPMENT IN THE WORLD” Telephone: (508) 842-2224
Fax: (508) 842-3893
Website:
www.weldengineering.com
Email:
[email protected]
March 1, 2018

IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

INDUSTRIAL PRODUCT SELECTION FOR
“MIGHTY-MAC” (HEAVY DUTY) FLUX RECOVERY EQUIPMENT

HEAVY CONTINUOUS DUTY VACUUMS

1A. MM-1500X (“MIGHTY-MAC 1500X”)

The New MM-1500X (Mighty-Mac 1500X) Heavy Duty Vacuum and
Dust Collector offers great new features. EXtremely rugged and
durable, eXtremely easy to maintain because large drawer pulls
out to empty flux dust and access filter for easy replacement.
This drawer and all internal covers are simple to remove by means
of four (4) wing nuts. EXtremely safe; micron filters remove
particles below one (1) micron. The air you breath will be much
cleaner. The MM-1500X also provides auto sensing dust
cleaning logic so filters are always automatically pulse cleaned as
they become dirty (with no operator intervention). Motor: 2 hp,
TEFC directly coupled to blower.

Input power: 230v/60hz/3ph
Input power: 230v/50hz/1ph

input power: 460v/60hz/3ph
Input power: 220v/50hz/3ph
Input power: 380-415V/50hz/3ph
Input power: 575v/60hz/3ph

1B. MM-1500X/P (“MIGHTY-MAC 1500X/P”)

MM-1500X/P (Mighty-Mac 1500X/P) Heavy Duty Vacuum unit only. Same as
2A above, except that instead of a dust drawer, dust filter chamber has a
hopper bottom. This enables continuous dumping of dust to a much larger
dust container below the Mighty-Mac (i.e FD-55 Dust Drum). Ideal for very
continuous recovery applications where regular emptying of dust drawer is
inconvenient..

TO ABOVE 1A PRICES ADD

NOTE: Teflon coated polyester filter for extra heavy duty applications.
Factory installed. One required.

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
