14. PFR-LD3 LID.

The PFR-LD3 Lid is for attachment to most manufacturers
standard OEM (Please specify model of hopper when ordering).
This lid will enable one to pressure feed flux to the hopper from a pressure
feed tank (PT-’X’ 00, HPT-’X’ 00, PFR3, LPFR-3, PFR-3000, HPFR-3000,
HPFR-HAMX-3000 etc.). Customer has choice of using 1/2”, 3/4”, or 1” I.D.
hose.

15. TNOZ-”x” PRESSURE TANK FLUX FEED NOZZLES.
1. TNOZ-1/2" - Pressure tank flux feed nozzle for 1/2"
I.D. hose. Nozzle fits 2" NPT female pipe fitting which is
standard on PFR-3, PT-”x”00, HPT-”x”00, PFR-3000, and
Lincoln K320 tanks.
(Please consult factory for non-standard sizes.)

2. TNOZ-3/4" - Same as above, except for 3/4" I.D. flux feed hose.

3. TNOZ-1" - Same as above, except for 1" I.D. flux feed hose.

4. TNOZ-DUAL-1/2" - Same as above, except for 1/2" I.D.
flux feed hose.

5. TNOZ-DUAL - 3/4" - Same as above, except for 3/4" I.D.
flux feed hose.

6. TNOZ-DUAL-1" - Same as above, except for 1" I.D.
flux feed hose.

16. TANK OR HOPPER HIGH OR LOW LEVEL SENSOR

1. High or low flux level warning lights and audible alarm for flux level for all
UNHEATED tanks and large hoppers (FH-100, 300 etc. and
PT-100, PT-300 and larger tanks).

A. SEN LFLS-115V Low flux level sensor (115V)
B. SEN LFLS-220V Low flux level sensor (220V)

C. SEN HFLS-115V High flux level sensor (115V)

D. SEN HFLS-220V High flux level sensor (220V)
E. SEN L-HFLS-115V High and low flux level sensor (115V)

F. SEN L-HFLS-220V High and low flux level sensor (220V)
