IMPORTANT NOTE: For diagrams of flux recovery system configurations, see the “Heavy Duty”
section of your catalog and look in the Technical Bulletin “TB-MM708,” or call us for engineering
assistance. (Ask us to send you the “TB-MM708” if it is not available to you.)

6. LPFR-3000 FLUX RECOVERY SYSTEM.

The LPFR-3000 flux recovery system (less the pressure tank)
mounts directly to the pressurized flux feed tank. The LPFR-
3000 screws on the tank in place of the top pressure cap;
recovers all unfused flux and transfers flux to pressure tank via
a butterfly valve and geared hand-wheel opener. Approximately
150 pound capacity. (Requires a “Mighty-Mac” vacuum to
provide vacuum power.) Available for PT-”x”00, HPT-”x”00,
Lincoln K320, and Miller pressure tanks. Please consult
factory for other pressure tanks. (See pg. 79, item 14
{MAGSEP-100} for optional magnetic separator and TB-
MM708 figure nos. 21, 22 and 23 for complete system require-
ments.)

7. HEATED HLPFR-3000 FLUX RECOVERY SYSTEM.

The HLPFR-3000 flux recovery system is the same as Item 6,
except heated. Continuous control to 250°F (121°C). Please
specify voltage, 115v/1ph/50-60hz or 220v/1ph/50-60hz. (See
pg. 79, item 14 {MAGSEP-100} for optional magnetic separator
and TB-MM708 figure nos. 21, 22 and 23 for complete system
requirements.)

OPTIONAL FTV-3000 AUTOMATIC FLUX TRANSFER
VALVE.........NEW PRODUCT!

Please see page 71 for details.115V/1PH/60-50HZ
(Other voltages available upon request.)
(Consult factory for pricing details.)

Input power: 115v/1ph/50-60hz and standard shop air (other
voltages available).

* SEE BULLETIN “TB-MM708” IN THE “HEAVY DUTY” SECTION OF CATALOG FOR SYSTEM DIAGRAMS*
